Name: ROAD CONSTRUCTION XCMG GR5505T PRO LAGER MINING MOTOR GRADER 30% GRADEABILITY 25MPA
Brand: Shanghai Zekun Machinery Co., Ltd.
SKU: GR5505T PRO
Price: 1.00 USD
Availability: InStock

Nhà > các sản phẩm > Máy chế tạo đường bộ >

ROAD CONSTRUCTION XCMG GR5505T PRO LAGER MINING MOTOR GRADER 30% GRADEABILITY 25MPA

XCMG GR5505T motor grader

compact mining motor grader

high-gradeability motor grader

Nguồn gốc:

Giang Tô, Trung Quốc (Đại lục)

Hàng hiệu:

XCMG

Chứng nhận:

IOS/CE

Số mô hình:

GR5505T PRO

Liên hệ với chúng tôi

Yêu cầu Đặt giá

ROAD CONSTRUCTION XCMG GR5505T PRO LAGER MINING MOTOR GRADER 30% GRADEABILITY 25MPA

Chi tiết sản phẩm

Điều khoản thanh toán và vận chuyển

Số lượng đặt hàng tối thiểu

Giá bán

Call for Price

chi tiết đóng gói

Container hoặc được vận chuyển bằng lô hàng Ro-ro hoặc hàng loạt

Thời gian giao hàng

7-15 ngày

Điều khoản thanh toán

T/T

Sản phẩm liên quan

2018 SEM919 Motor Grader để bán

Nhận được giá tốt nhất

26ton XCMG XP263 Lốp xe lăn Trung Quốc Giai đoạn III Thiết bị xây dựng đường bộ

Nhận được giá tốt nhất

2.6ton XCMG XD100 Vibratory Roller EU giai đoạn V

Nhận được giá tốt nhất

23ton XCMG 3Y263J Static Three Drum Roller Trung Quốc

Nhận được giá tốt nhất

Liên hệ với chúng tôi

Liên hệ ngay bây giờ

Mô tả sản phẩm

Model: Motor Grader	Condition: Brand New	Application: Construction
Brand Name: XCMG	Model Number:GR5505T Pro	Certification: ISO,CE
Rated Working Pressure: 25MPa	Max. Gradeability: ≥30%	Dimension: 1643045604810mm
Total Weight: 74000kg	Engine: 2806D-E18TA	Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year	Color: Yellow	After-sales Service Provided: Engineers available to service machinery overseas

Item			GR5505T PRO
Basic parameters	Engine model		2806D-E18TA
	Rated power/speed		447kW/2100rpm
	Machine dimension(standard)		1643045604810mm
	Machine weight(standard)		74000kg
	Tire specification		29.5R29
	Ground clearance (Front axle)		890mm
	Wheel track		3650mm
	Axle distance between front and rear		10460mm
	Wheel base between middle and rear		2240mm
Performance parameters	Drive speed, forward		4.6, 5.9, 8.7, 11.7, 17.7,25.1, 32.2,42.7km/h
	Drive speed, reverse		4.5,8.7,17.2, 32.6km/h
	Traction force f=0.75		≥390kN
	Maximum gradeability		≥30%
	Tire inflation pressure		500kPa
	Work system pressure		25MPa
	Transmission box pressure		/
Working parameters	Maximum steering angle, front wheel		±48°
	Allowable tilt angle, front wheel		±18°
	Maximum oscillation, front axle		±16°
	Maximum oscillation, balance box		Front 20°, rear 20°
	Maximum steering angle, frame		±25°
	Minimum turning radius		12.5m
	Blade	Maximum it above ground	460mm
		Maximum cutting depth	553mm
		Maximum tit angle	55°
		Cutting angle	40°
		Swivel angle	340°
		Length * height	7300x1025mm
Capacities	Coolant		75L
	Fuel tank		1100L
	Engine		72L
	Transmission box		120L
	Balance box		7OL
	Main reducer and wheel reducer		83L
	Hydraulic oil		280L

ROAD CONSTRUCTION XCMG GR5505T PRO LAGER MINING MOTOR GRADER 30% GRADEABILITY 25MPA 2

• Guarantee of delivery
Support online transactions through Alibaba, Verified supplier
-------------------------------------------------------------------------------------------------------------------------------------------
•Which payment terms can you accept?
Normally we can work on the T/T term or L/C term.
1. On T/T term, 30% down payment is required in advance, and 70% balance shall be settled prior to shipment, or against the copy
of original B/L for long-term cooperating clients.
2. On L/C term, a 100% irrevocable L/C without “soft clauses” from an internationally recognized bank can be accepted. Please seek the advice from the individual manager whom you work with.
-------------------------------------------------------------------------------------------------------------------------------------------
•Which INCOTERMS 2010 terms can you work?
We are a professional and sophisticated international player, can handle all INCOTERMS 2010 terms, and we normally work on regular terms such as EXW,FOB,CFR,CIF.
-------------------------------------------------------------------------------------------------------------------------------------------
•How long will your price be valid?
We are a tender and friendly supplier, never greedy on windfall profit. Our price remains stable throughout the year, We only adjust our price based on two situations.
1. The rate of USD, and RMB varies significantly according to the international currency exchange rates;
2. Manufacturers/Factories adjusted the machine price, because of the increasing labor cost and raw material cost.
-------------------------------------------------------------------------------------------------------------------------------------
•WHAT LOGISTICS WAYS CAN YOU WORK FOR SHIPMENT?
We can ship construction machinery with various transportation tools.
1. For 80% of our shipment, the machine will go by sea, to all main continents such as Africa, South America, Middle East. Oceania and Southeast Asia etc., either by container or RoRo / Bulk shipment.
2. For inland neighborhood countries of China, such as Russia, Mongolia, Kazakhstan, Kyrgyzstan, Tajikistan, Uzbekistan, Turkmenistan, etc., we can send machines by road or railway.
